QS273 40H Peak 8000W V3 150mm Dropout Electric Bicycle Hub Motor 100KPH for Electric Bicycle Motor (4T)
Product details
| Management number | 218276742 | Release Date | 2026/05/03 | List Price | US$319.20 | Model Number | 218276742 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
8000W 273 40H V3 E-spoke hub motor Motor Type: BLDC Permanent Magnet Outer Rotor In-Wheel Hub Motor With Hall Sensor Brand: QS Motor,QSMOTOR Motor Design: Double axle without rim (not integrated), 36 spoke holes, OD 4.2mm Matching Rim size: 17inch, 18inch, 19inch, 21inch moped wheel. Magnet Height: 40mm, 16 pole pairs Stator: Aluminmum Core Rated Power: 4000W Rated Voltage: 72V as default Max Speed: 120KPH kV: 11.46/12.46/13.54/15.69/17.71etc. Max Torque: approx 250N.m Max Efficiency: 86-91% Continuous Battery Current:69A (72V) Peak Battery Current: 138A (72V) Suggest Peak Phase Current: 448-561A (depend on the kV) Thermic Probe: KTY83/122 (as default, optional) Working Temperature: 70-120℃ , peak 150 ℃ Brake type: Bike Disc brake, PCD6*44mm(as default) Drop-outs/Rear Fork Width for installation: 150mm Dual Hall Set with waterproof connectors 16mm ² ; Cross Section of Phase Wire (not include insulation layer) Hall Sensor Phasing angle: 120 degree Waterproof Grade: IP54 Color: Black N.W./G.W.: 18.2kg/20.0kg Package Dimension: 43cm*43cm*41cm/piece
- QS 273 8000W high quality Motor
- Max Speed can reach 120KPH at 72V
- this motor Drop-outs/Rear Fork Width for installation: 150mm
- Motor axle size :M16*12mm,please check frame install plug size
- Matching Rim size: 17inch, 18inch, 19inch, 21inch moped wheel.
| UPC | 784300584476 |
|---|---|
| Model | nbp8000 |
| Speed | 80 Kilometers per Hour |
| Voltage | 72 Volts |
| Brand Name | Generic |
| Horsepower | 8000 Watts |
| Model Name | nbp |
| Part Number | nbp011 |
| Manufacturer | NIUBO POWER |
| Included Components | motor |
| Warranty Description | one year |
